Cost-effective 2D QR 1D Bar code scanner USB support most countries keyboard layout suffix prefix editing

Best Offers Cost-effective 2D QR 1D Bar code scanner USB support most countries keyboard layout suffix prefix editing

Product ID : 32872687303

Price : $42

Discount Price : $87.12

* Price Update at : Jully, 25 2019 *

VISIT WEBSITE NOW

Item specifics

•
  Brand Name:
  YK&SCAN



•
  Scan Speed:
  100 scans/second



•
  Type:
  Barcode Scanner



•
  Optical Resolution:
  600*600



•
  Scan Element Type:
  CMOS



•
  Interface Type:
  USB



•
  Scan Breadth:
  A3



•
  Model Number:
  YK-MK30



•
  Novelty:
  New



•
  Scanning Light Source:
  LED



•
  Colour Depth:
  32 Bit



•
  Product Type:
  Bar Code Scanner


Product Description

Performance	Sensor		640*480 CMOS
	Symbologies	1D	EAN-8、EAN-13、EAN-13 2 add-on、 EAN-13 5 add-on、ISBN、UPC-A、UPC-E、Code 39、Code 39FULL ASCII、Code 93、、Code 32、Code 128、Codabar、Interleaved 2 of 5
		2D	PDF417,Data Matrix,QR-code
	Depth of field		Tested code	Min	Max
			6.6mil  code39	6cm	8cm
			UPC-13mil	4cm	18cm
			20 mil  code39	8cm	18cm
			20 mil QR Code	5cm	16cm
	System compatibility		Linux，Windows XP、7、8、 10
	Scan Mode		Manual key scan
	Keyboard Support		English, French, Italian, German, Spanish, Turkish Q, Belgian (French)
	Language		Simplified Chinese characters (under Win system)
	Invoice Function		Support (only for the Chinese market) (under Win system)
	Min Resolution		Code 39 6.6mil
	Decode Capacity		1D/2D Codes on printed paper and mobile screen
	Motion Tolerance		2.2 m/s
	Print contrast		25%
	Secondary development		Not support
	Barcode Output Editing		Prefix&suffix
	Scan Angle		Roll ±360°，Pitch ±60°，Skew ±70°
Environmental	Drop		Withstand 3 drops from 1.5 meters
	Sealing		IP54
	Operating Temperature		-20-55℃
	Storage Temperature		-20-60℃
	Operating Humidity		5-95% Non-condensing
	Storage Humidity		5-95% Non-condensing
	Ambient Light		0-70000LUX
Human-machine interaction	Indicator light		Blue power indicator, decoding flashes
	Buzzer		Start prompt, decoding success prompt
	Trigger		Trigger Scan
Physical	Net Weight		122g
	Packing Weight		297g
	Host size (L * W * H mm)		167mm*73.5mm*105.4mm
	Packing size(L * W * H mm)		185mm*110mm*83mm
	Cable length		180CM(±3CM)
	Interface		USB port (free drive), USB virtual serial port (installation driver), serial port (free drive)
	Working Voltage		5V
	USB Manual Scan	Standby Power	61mA/0.305W
		Operating Power	323mA/1.615W
		Max Power	331mA/1.655W
	Serial Port Manual Scan	Standby Power	66mA/0.33W
		Operating Power	320mA/1.6W
		Max Power	341mA/1.705W





Packaging Details

•
  Unit Type:
  piece



•
  Package Weight:
  0.5kg (1.10lb.)



•
  Package Size:
  20cm x 13cm x 10cm (7.87in x 5.12in x 3.94in)
